APC Smart-UPS X 750VA 600Watt Rack/Tower LCD 230V

รหัสสินค้า : SMX750I
APC
สถานะ

สั่งจองสินค้า


  • SMX Series, Rack/Tower convertible
  • มีหน้าจอ LCD และ SmartSlot สำหรับใส่ network card (ต้องซื้อเพิ่มเป็น option)
  • รองรับการเชื่อมต่อ battery pack สูงสุด 10 pack
  • Battery Expansion : SMX48RMBP2U
  • Output power capacity 600Watts / 750VA
  • Max Configurable Power (Watts) 600Watts / 750VA
  • Nominal Output Voltage 230V
  • Output Voltage Distortion Less than 5%
  • Output Frequency (sync to mains) 50/60Hz /- 3 Hz
  • Topology Line Interactive
  • Waveform type Sine wave
  • Output Connections (8) IEC 320 C13 (Battery Backup)


ราคาสินค้ายังไม่รวมภาษีมูลค่าเพิ่ม
---> กรุณาตรวจสอบสินค้าก่อนสั่งซื้อทุกครั้ง <---

฿22,900.00 ฿24,500.00

สั่งจองสินค้า

APC Smart-UPS. APC Smart-UPS X 750VA 600Watt Rack/Tower LCD 230V | SMX750I

Output

  • Output power capacity 600Watts / 750VA
  • Max Configurable Power (Watts) 600Watts / 750VA
  • Nominal Output Voltage 230V
  • Output Voltage Distortion Less than 5%
  • Output Frequency (sync to mains) 50/60Hz /- 3 Hz
  • Topology Line Interactive
  • Waveform type Sine waveOutput Connections (8) IEC 320 C13 (Battery Backup)

Input

  • Nominal Input Voltage 230V
  • Input frequency 50/60 Hz /- 3 Hz (auto sensing)
  • Input Connections IEC-320 C14
  • Cord Length 1.83meters
  • Input voltage range for main operations 160 – 286V
  • Input voltage adjustable range for mains operation 151 – 302V
  • Number of Power Cords 1
  • Other Input Voltages 220, 240

Batteries & Runtime

Communications & Management

  • Interface Port(s) SmartSlot , USB
  • Control panel Multi-function LCD status and control console
  • Audible Alarm Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
  • Available SmartSlot™ Interface Quantity 1

Surge Protection and Filtering

  • Surge energy rating 645Joules
  • Filtering Full time multi-pole noise filtering : 5% IEEE surge let-through : zero clamping response time : meets UL 1449

Physical

  • APC Smart-UPS X 750VA 600Watt Rack/Tower LCD 230V SMX750I
  • Maximum Height 89mm , 8.9cm
  • Maximum Width 432mm , 43.2cm
  • Maximum Depth 490mm , 49.0cm
  • Rack Height 2U
  • Net Weight 22.05kg
  • Shipping weight 26.5kg
  • Shipping Height 246mm , 24.6cm
  • Shipping Width 589mm , 58.9cm
  • Shipping Depth 620mm , 62.0cm
  • Color Black
  • Units per Pallet 8.0

Environmental

  • Operating Environment 0 – 40 °C
  • Operating Relative Humidity 0 – 95 %
  • Operating Elevation 0-3000meters
  • Storage Temperature -15 – 45 °C
  • Storage Relative Humidity 0 – 95 %
  • Storage Elevation 0-15000meters
  • Audible noise at 1 meter from surface of unit 40.0dBA
  • Online thermal dissipation 69.0BTU/hr

Conformance

  • Approvals CE, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDE
  • Standard warranty 3 years repair or replace (excluding battery) and 2 year for battery

Sustainable Offer Status

  • RoHS Compliant
  • REACH REACH: Contains No SVHCs
  • PEP Available in Documentation tab
  • EOLI Available in Documentation tab
รหัสสินค้า: SMX750I หมวดหมู่: , , ,
Brand
Brand

Product Type
Product Type

UPS

More
UPS VA

750 VA

UPS Watts

600 Watts

UPS Application

Network and Server

UPS Topology

UPS Power Factor

0.8

UPS Full Load Backup Time

14 min

UPS Half Load Backup Time

37 min

UPS External Battery

รองรับการต่อ Battery เพิ่ม

UPS Max Battery Pack Support

10 Pack

UPS Network Card Support

Network Card Support

UPS Software

PowerChute Business Edition (PCBE)

UPS Warranty

3Y Onsite 5×8
