Cisco Catalyst 9200L 24-port data only 4x1G Network Advantage Switch

รหัสสินค้า : C9200L-24T-4G-A
Cisco
Availability:

ตรวจสอบราคา สต็อก และระยะเวลาการสั่งซื้อสินค้าทุกครั้ง


  • Downlinks total 10/100/1000 or PoE+ copper ports : 24 ports data
  • Uplink configuration : 4x 1G fixed uplinks
  • Default primary AC power supply : PWR-C5-125WAC
  • Software : Network Advantage
  • Stacking bandwidth : 80 Gbps
  • DRAM : 2 GB
  • Flash : 4 GB
  • Switching capacity : 56 Gbps
  • Forwarding rate : 41.66 Mpps

--- กรุณาตรวจสอบสินค้าก่อนสั่งซื้อทุกครั้ง ---

฿ 39,600.00฿ 134,400.00
฿ 42,372.00฿ 143,808.00 (ราคารวมภาษี)




Cisco Catalyst 9200L 24-port data only 4x1G Network Advantage Switch

C9200L-24T-4G-A Overview

C9200L-24T-4G-A is the Catalyst 9200L 24-port Data 4x1G uplink Switch, with Network Advantage software. Cisco® Catalyst® 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree, Catalyst 9200 Series switches offer simplicity without compromise – it is secure, always on, and IT simplified.



Cisco Catalyst 9200L 24-port GE 4x1G Quick Specs

Table 1 shows the Quick Specs.

Model

C9200L-24T-4G-A

Downlinks total 10/100/1000 or PoE+ copper ports

24 ports data

Uplink configuration

4x 1G fixed uplinks

Default primary AC power supply

PWR-C5-125WAC

Fans

Fixed redundant

Software

Network Advantage

Stacking bandwidth

80 Gbps

DRAM

2 GB

Flash

4 GB

Switching capacity

56 Gbps

Forwarding rate

41.66 Mpps

Chassis Dimensions

1.73 x 17.5 x 11.3 in

4.4 x 44.5 x 28.8 cm

Weight

4.35 Kg





Cisco Catalyst 9200L 24-port GE 4x1G Product Details

Catalyst 9200 series provides these highlights:

  • Up to 48 ports of full Power over Ethernet Plus (PoE+) capability
  • Resiliency with Field-Replaceable Units (FRU) and redundant power supply, fans, and modular uplinks
  • Flexible downlink options with data or PoE+
  • Operational efficiency with optional backplane stacking, supporting stacking bandwidth up to 160 Gbps
  • UADP 2.0 Mini with integrated CPU offers customers optimized scale with better cost structure
  • Enhanced security with AES-128 MACsec encryption, policy-based segmentation, and trustworthy systems
  • Layer 3 capabilities, including OSPF, EIGRP, ISIS, RIP, and routed access
  • Advanced network monitoring using Full Flexible NetFlow
  • Cisco Software-Defined Access (SD-Access):
    • Simplified operations and deployment with policy-based automation from edge to cloud managed with Cisco Identity Services Engine (ISE)
    • Network assurance and improved resolution time through Cisco DNA Center™
  • Plug and Play (PnP) enabled: A simple, secure, unified, and integrated offering to ease new branch or campus device rollouts or updates to an existing network
  • Cisco IOS XE: A Common Licensing based operating system for the enterprise Cisco Catalyst 9000 product family with support for model-driven programmability and streaming telemetry
  • ASIC with programmable pipeline and micro-engine capabilities, along with template-based, configurable allocation of Layer 2 and Layer 3 forwarding, Access Control Lists (ACLs), and Quality of Service (QoS) entries



SKU: C9200L-24T-4G-A Categories: , , , Tags: , ,
Brand
Brand

Product Type
Product Type

Switch

Warranty
Warranty

Limited Lifetime

More
Total Port

24x Gigabit Ethernet
4x 1G SFP

Network Downlink

24 Ports

Network Uplink

1G Uplink

PoE Support

None

DNA License

3 Years
5 Years
None

Hardware Support

1 Years 8x5xNBD
2 Years 8x5xNBD
3 Years 8x5xNBD
Standard

Throughput

41.66 Mpps

Switch Capacity

56 Gbps

MAC address

up to 16K addresses
