HPE ProLiant DL320 Gen11 Bronze 3408U P57685-B21
HPE ProLiant DL320 Gen11 Bronze 3408U P57685-B21
HPE Proliant DL320 Gen11 Xeon Bronze 3408U 16GB 4LFF VROC 3x4TB (P57685-B21)
- Intel Xeon Bronze 3408U 1.8GHz 8 core, 8 Thread, 22.5 MB L3, 125W
- One processor (Support 1 CPU)
- 16GB (1x16GB) UDIMM DDR5 4800 MT/s
Notes: Runs at 4000MT/s due to processor limitation
- HPE embedded 2-port 1 GbE Ethernet adapter
- Intel VROC – Embedded SATA controller (AHCI or Intel SATA software RAID controller)
Software RAID (Windows only) Support RAID-0, 1, 5, 10
- 4 LFF Hot-Plug Hard disk Bay
- 3x 4TB SATA 7.2K LFF LP MV HDD
- HPE DL3XX Gen11 1U Bezel Kit
- Not included (Optical Drive options available)
- 2 x16 FHHL PCIe Gen5
- 2 x 500W Platinum Hot Plug Redundant Power Supply
- HPE iLO6 Standard
- TPM (Trusted Platform Module)
- 1U Rack, Free! POWER CORD 10A C13(Third party)
- 3-Year Standard Warranty Next Business Day Support (Parts, Labor, Onsite)
3-Y TechCare Essential DL320 Gen11 HW Service (24×7)
รับสิทธิ์แลกซื้อ UPS ในราคา
- APC Easy UPS On-Line SRV 2000VA 1800W Rack (SRV2KRIRK-E) 24,000 บาท (Ex Vat)
- APC Smart-UPS C 1500VA 900W Rack (SMC1500I-2U) 23,500 บาท (Ex Vat)
รับสิทธิ์แลกซื้อ Windows Server ในราคา
- Windows Server 2022 Standard ROK (P46171-371) 33,500 บาท (Ex Vat)
|Processor core available||8 core|
|Processor cache||22.5 MB L3|
|Memory type||HPE DDR5 SmartMemory|
|Infrastructure management||Included – HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download). Optional – HPE iLO Advanced, and HPE OneView Advanced.|
|System fan features||Five standard fans|
|Power supply type||HPE 500W Flex Slot Platinum Hot Plug Power Supply|
|Expansion slots||One PCIe Gen5 & One OCP 3.0 PCIe Gen5|
|Network controller||HPE embedded 2-port 1 GbE Ethernet adapter|
|Storage controller||Intel VROC – Embedded SATA controller (AHCI or Intel SATA software RAID controller)|
|Warranty||3/3/3: Server Warranty includes three years of parts, three years of labor, and three years of onsite support coverage. Additional information regarding worldwide limited warranty and technical support is available at: https://h20564.www2.hpe.com/hpsc/wc/public/home. Additional HPE support and service coverage, to supplement the product warranty, is available. For more information, visit https://www.hpe.com/support|
|Processor name||Intel® Xeon® Bronze 3408U (8 core, 1.8 GHz, 22.5 MB L3, 125W)|
|Processor number||1 processor included|
|Processor speed||1.8 GHz|
|Included hard drives||None ship standard, 8 SFF SAS/SATA/NVMe drives supported|
|Optical drive type||Optional HPE 9.5mm SATA DVD-RW Optical Drive, HPE Mobile USB DVD-RW Drive|
|Security||UEFI Secure Boot and Secure Start support. Intel® Software Guard Extensions (SGX) support. Immutable Silicon Root of Trust. Optional Trusted Supply Chain, iLO Security modes, TPM, Chassis Intrusion detection and Bezel Locking kits.|
|Minimum dimensions ( H x W x D)||23.62 x 36.06 x 9.49 in|
|Minimum dimensions ( H x W x D)||60 x 91.6 x 24.1 cm|
|Detailed product description||HPE ProLiant DL320 Gen11 server with one Intel® Xeon® Scalable 4410Y processor, 1x 16 GB single rank memory, Broadcom MegaRAID MR408i-o x8 Lanes 4 GB Cache 6G SATA/12G SAS/16G NVMe OCP SPDM Storage Controller for HPE Gen11 with HPE 96W Smart Storage Lithium-ion Battery with 145 mm Cable Kit, eight small form factor SAS/SATA/NVMe drive bays, five standard fans, one HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply, and a 3/3/3 warranty|
|DIMM capacity||16 GB|
- Powered by the 4th Gen Intel® Xeon® Scalable Processors with next-generation 5nm technology that supports up to 32 cores at 270W and 16 DIMMs of DDR5 memory up to 4800 MT/s.
- 16 DIMMs per processor for up to 2 TB total DDR5 memory with increased memory bandwidth and performance, and lower power requirements.
- Advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 2×16 PCIe Gen5 and 1 OCP3.0 slots.
- Includes the new HPE Integrated Lights-Out 6 (iLO 6) server management software that enables you to securely configure, monitor, and update your HPE ProLiant Gen11 servers seamlessly, from anywhere.
- Supports hot-pluggable or internal, high-availability RAID1 NVMe M.2 boot options.
Intuitive Cloud Operating Experience: Simple, Self-service, and Automated
HPE ProLiant DL320 Gen11 servers are engineered for your hybrid world. Moreover, the HPE ProLiant DL320 Gen11 servers simplify the way you control your business’s compute—from edge to cloud—with a cloud operating experience.
Transform business operations and pivot your team from reactive to proactive with global visibility and insight through a self-service console. Additionally, automate tasks for efficiency in deployment, instant scalability, and seamless, simplified support and lifecycle management, thus reducing tasks and shortening maintenance windows.
These experiences are engineered and built into all HPE ProLiant Gen11 servers, whether purchased as physical servers or consumed as-a-service using HPE GreenLake as your compute and storage demands grow.
Simplify and secure server management from edge to cloud with HPE GreenLake for Compute Ops Management. Notably, HPE GreenLake for Compute Ops Management is an as-a-service compute management experience that delivers greater simplicity, agility, and speed across your entire compute landscape, globally.
Trusted Security by Design: Uncompromising, Fundamental, and Protected
The HPE ProLiant DL320 Gen11 server is tied into the silicon root of trust and the 4th Gen Intel® Xeon® Scalable Processor, a dedicated security processor embedded in the Intel Xeon system on a chip (SoC), to manage secure boot, memory encryption, and secure virtualization.
Furthermore, HPE ProLiant Gen11 servers use the silicon root of trust to anchor the firmware of an HPE ASIC, creating an immutable fingerprint for the Intel® Xeon® Processor that must be matched exactly before the server will boot. Consequently, this ensures malicious code is contained and healthy servers are protected.
Moreover, HPE ProLiant Gen11 servers continuously protect healthy servers by providing rapid detection of security-compromised servers, even to the point of not allowing them to boot if it identifies and contains malicious code. Additionally, they secure servers at the edge with IDevID certificates installed by default.
Notably, HPE ProLiant Gen11 servers provide automated recovery from a security event, including restoration of validated firmware and facilitating recovery of the operating system, application, and data connections. This ensures the fastest path to bring a server back online and into normal operations.
From silicon to software, from factory to cloud, and from generation to generation, HPE ProLiant Gen11 is engineered with a fundamental security approach to defend against increasingly complex threats. Furthermore, this is achieved through an uncompromising commitment to constant security advancements that are built into our DNA.
Optimized Performance for your Workloads: Accelerated, Open, and Efficient
The HPE ProLiant DL320 Gen11 server is an excellent choice for virtualized workloads such as software-defined compute, CDN, and VDI, and secure edge apps that require balancing processor, memory, and network bandwidth.
Additionally, harness major computer performance. Notably, the HPE ProLiant DL320 Gen11 server is powered by 4th Gen Intel® Xeon® Scalable Processors with modern 5nm technology that support up to 32 cores and 270W TDP.
Furthermore, enjoy advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus. This is achieved with up to 2×16 PCIe Gen5 and 1 OCP slots to improve I/O throughput and reduce latency.
Moreover, utilize 16 DIMM channels per processor for up to 2 TB total DDR5 memory with increased memory bandwidth and performance, and lower power requirements.
Additionally, benefit from real-time operational feedback on server performance plus recommendations for fine-tuning BIOS settings to customize for changing business needs.
The HPE ProLiant DL320 Gen11 server is supported by HPE GreenLake to simplify IT. With 24×7 monitoring and management, our experts do the heavy lifting to manage your environment with services built into consumption-based solutions.
Furthermore, Hewlett Packard Enterprise provides customers choice in how they acquire and consume IT. In addition to traditional financing and leasing, HPE offers options that free trapped capital, accelerate infrastructure updates, and provide for on-premises pay-per-use consumption with HPE GreenLake.
Moreover, rapidly deploy a broad portfolio of cloud services such as containers, compute, virtual machines (VMs), accelerated storage, data protection, and more. Workload-optimized, preconfigured solutions can be quickly onboarded, accelerating your agility.
